A. Product Overview
Item | Description |
Activity Detection | Monitoring the status of doors and windows in your room |
Pushing | After pushing the push message on the App, when the door magnet status changes, the cloud sends a push push message to the mobile phone. Note: When continuously triggered, the cloud pushes only one push per minute. |
Battery detection | Battery charge report |
Linkage | Add products to be linked (air conditioning and curtains...) through the software, and turn on or off the added air conditioners (air conditioners and curtains...) when the door magnet status changes. |
Record preview | Viewing record in 7 days before |
Item | Description |
Reset/Restart | Red light off |
Distribution status :EZ mode | Red flash |
AP mode | Red flashing slowly |
Working mode | Red light off |
Data report | Red light flashes once |
Item | Description |
Transmission Protocol | ZigBee V3.0 |
Wireless frequency | 2.4GHz |
Working voltage | 2.2V-3V |
Detection range | Temperature and humidity near a fixed location |
Operating current (reported) | 80 mA (ZigBee) |
Standby current | <5 uA |
Battery life | more than 6 months (1300mAh battery calculation) |
Application range | Indoor use |
Mounting method | Paste or screw (combination structure) |
Transmission distance | indoor 10 to 30 meters, outdoor 30 to 50 meters (for reference only, different application environments and transmission methods will lead to some differences in parameters) |
Battery Type | Button 1pc |
Physical Switch | 1 pc |
Indicator light | 1 pc |
Buzzer | 1 pc |
